Small controllers Preset type
Pretimed small controllers are quite simple and electronic. These devices have the ability to detect the amount of traffic on a daily basis.
Introduction of small pre-scheduled controllers
Pretimed small controllers are quite simple and electronic. These devices have the ability to detect the amount of traffic on a daily basis. Based on the results of their traffic observations, these devices will be able to make detailed plans for the amount of green or red light at each intersection during the next day.
Since the traffic pattern on a street is in most cases regular and repetitive, better decisions about traffic scheduling can be considered. Timer These controllers read information from the device memory and perform stop and pass operations accordingly. It is also possible to schedule weekly based on even and odd plans through these controllers.
Features of small pre-scheduled controllers
- Easy and simple installation
- How the controllers work and are user-friendly
- Ability to set a predefined pattern to control traffic on any street
- Flexibility and the ability to change the process of traffic execution according to its amount
- Reasonable and economical price
Applications of small pre-scheduled controllers
- Intersection with heavy traffic volume
- Crossroads with a regular pattern of traffic
Technical specifications of small pre-scheduled controllers
| Technical Specifications | ST3030 | ST5035 |
|---|---|---|
| Maximum number of signal groups | 4 | 4 |
| Maximum number of phases | 4 | 8 |
| Phase type | Simple separate | Overlapping complex, early release, late release, day and night phase |
| Schedules | 8 plans per day, 4 days a week, 1 month a year | 16 plans per day, 4 days a week, 8 months a year |
| Working modes | Pre-time, fixed-time, wink and manual | Pre-time, blinking and manual |
| How to program the controller | Through the panel | Via laptop and flash |
| Upgradeability to smart controller | Optionally by adding a detector loop module | Optionally by adding a detector loop module |
| Hardware structure | Two main modules | Rack mount type |
| Main processor | ATMEGA32 | ARM_LPC2368 |
| Operator panel | Optionally 2x16 display and 24 keypad | Optionally 4x20 display and 24 keypad |
| Police panel | option | option |
| Installation method | On the mast | On the mast |
| Color | Rital and blue combination of static type | Rital and blue combination of static type |
| Cabinet dimensions | WxDxH=30x17x45 cm | WxDxH=30x17x45 cm |
| The first year of construction | 1391 | 1391 |
Sample customers
Tehran Municipality
Isfahan Municipality
Tabriz Municipality
Tehran Road Police
Mashhad Municipality
